  • E704A爆炸图.jpg

In situ Raman spectroscopy electrical test cell E704A

1, can be ventilated, can be tested under gas circulation conditions. 2, the negative electrode diaphragm protection, reduce the loss of the negative electrode, effectively extend the experimental time.

Classification:

In-situ Raman Electrolytic Cell

Key words:

electrode


Messages
In Situ Raman Spectroscopy Electrical Test Cell E704A-Two Electrode Ventilated Negative Protection
MaterialBody material: 316 stainless steel
Sealing parts material: perfluoro, fluorine rubber
Window material: sapphire
Main parameters

Outer dimension of main body: Φ54 × 19
Window valid: Φ5( Φ8、Φ10 optional)
Sample distance window 2mm
Window thickness: 0.5mm
Suitable for installation sample size: Φ12-Φ16(Window valid: Φ5)、Φ15-Φ16(Window valid: Φ8

Inner cavity diameter: Φ16

Uses and features1, can be ventilated, can be tested under gas circulation conditions.
2, the negative electrode diaphragm protection, reduce the loss of the negative electrode, effectively extend the experimental time.
